Personal computer
-
Printer
-
POS(Point of sales) terminals
-
Security system
-
Fax machine
- Modem, router
APPLICATIONS:
Product parameters:
| Model | AK650 | |
| Installation method | Tower type UPS | |
| Main topology | L+N+PE | |
| Capacity | 650VA/390W | |
| Input | ||
| Input voltage | 110/120VAC or 220/230/240VAC | |
| Voltage range | 86-140VAC or 170-285VAC | |
| Input frequency | 50/60Hz | |
| Factor | 0.999 | |
| Output | ||
| Main topology | L+N+PE | |
| Output voltage | 110/120VAC or 220/230/240VAC | |
| Voltage range (battery mode) | ±10% | |
| Frequency synchronous range | 50Hz or 60Hz ± 1HZ | |
| Factor | 0.6 | |
| Transfer time | 6ms | |
| Output waveform | Simulated sine wave | |
| Communication and Management | ||
| Communication interface | RS232/USB/RJ11/RJ45 | |
| Control panel | Multi functional LCD,status and display console | |
|
Standard UPS |
||
|
Standard UPS battery |
Battery type | VRLA |
| Charging current | 1A | |
| Battery voltage | 12V | |
| Battery capacity | 7AH | |
|
Machinedata |
Size (MM) | 330*100*150 |
| Weight (KG) | 5.2KG | |
|
Packing data |
Size (MM) | 390*313*440 |
| Weight (KG) | 20.8KG | |
| UPS Number | 4 | |
|
Environment |
||
| Operating humidity | 20%-95%(No condensing) | |
| Relative temperature | -25-55℃C | |
| Maximum noise level at full load (at 1m) | ＜40dBA@1M | |
Product parameters:
| Model | AK850 | |
| Installation method | Tower type UPS | |
| Main topology | L+N+PE | |
| Capacity | 850VA/510W | |
| Input | ||
| Input voltage | 110/120VAC or 220/230/240VAC | |
| Voltage range | 86-140VAC or 170-285VAC | |
| Input frequency | 50/60Hz | |
| Factor | 0.999 | |
| Output | ||
| Main topology | L+N+PE | |
| Output voltage | 110/120VAC or 220/230/240VAC | |
| Voltage range (battery mode) | ±10% | |
| Frequency synchronous range | 50Hz or 60Hz ± 1HZ | |
| Factor | 0.6 | |
| Transfer time | 6ms | |
| Output waveform | Simulated sine wave | |
| Communication and Management | ||
| Communication interface | RS232/USB/RJ11/RJ45 | |
| Control panel | Multi functional LCD,status and display console | |
|
Standard UPS |
||
|
Standard UPS battery |
Battery type | VRLA |
| Charging current | 1A | |
| Battery voltage | 12V | |
| Battery capacity | 9AH | |
|
Machinedata |
Size (MM) | 330*100*150 |
| Weight (KG) | 5.7KG | |
|
Packing data |
Size (MM) | 390*313*440 |
| Weight (KG) | 22.8KG | |
| UPS Number | 4 | |
|
Environment |
||
| Operating humidity | 20%-95%(No condensing) | |
| Relative temperature | -25-55℃C | |
| Maximum noise level at full load (at 1m) | ＜40dBA@1M | |
Product parameters:
| Model | AK1000 | |
| Installation method | Tower type UPS | |
| Main topology | L+N+PE | |
| Capacity | 1000VA/600W | |
| Input | ||
| Input voltage | 110/120VAC or 220/230/240VAC | |
| Voltage range | 86-140VAC or 170-285VAC | |
| Input frequency | 50/60Hz | |
| Factor | 0.999 | |
| Output | ||
| Main topology | L+N+PE | |
| Output voltage | 110/120VAC or 220/230/240VAC | |
| Voltage range (battery mode) | ±10% | |
| Frequency synchronous range | 50Hz or 60Hz ± 1HZ | |
| Factor | 0.6 | |
| Transfer time | 6ms | |
| Output waveform | Simulated sine wave | |
| Communication and Management | ||
| Communication interface | RS232/USB/RJ11/RJ45 | |
| Control panel | Multi functional LCD,status and display console | |
|
Standard UPS |
||
|
Standard UPS battery |
Battery type | VRLA |
| Charging current | 1A | |
| Battery voltage | 12V | |
| Battery capacity | 9AH | |
|
Machinedata |
Size (MM) | 330*100*150 |
| Weight (KG) | 5.8KG | |
|
Packing data |
Size (MM) | 390*313*440 |
| Weight (KG) | 23.2KG | |
| UPS Number | 4 | |
|
Environment |
||
| Operating humidity | 20%-95%(No condensing) | |
| Relative temperature | -25-55℃C | |
| Maximum noise level at full load (at 1m) | ＜40dBA@1M | |
Product parameters:
| Model | AK1200 | |
| Installation method | Tower type UPS | |
| Main topology | L+N+PE | |
| Capacity | 1200VA/720W | |
| Input | ||
| Input voltage | 110/120VAC or 220/230/240VAC | |
| Voltage range | 86-140VAC or 170-285VAC | |
| Input frequency | 50/60Hz | |
| Factor | 0.999 | |
| Output | ||
| Main topology | L+N+PE | |
| Output voltage | 110/120VAC or 220/230/240VAC | |
| Voltage range (battery mode) | ±10% | |
| Frequency synchronous range | 50Hz or 60Hz ± 1HZ | |
| Factor | 0.6 | |
| Transfer time | 6ms | |
| Output waveform | Simulated sine wave | |
| Communication and Management | ||
| Communication interface | RS232/USB/RJ11/RJ45 | |
| Control panel | Multi functional LCD,status and display console | |
|
Standard UPS |
||
|
Standard UPS battery |
Battery type | VRLA |
| Charging current | 1A | |
| Battery voltage | 24V | |
| Battery capacity | 7AH | |
|
Machinedata |
Size (MM) | 365*140*165 |
| Weight (KG) | 11.9KG | |
|
Packing data |
Size (MM) | 450*436*250 |
| Weight (KG) | 23.8KG | |
| UPS Number | 2 | |
|
Environment |
||
| Operating humidity | 20%-95%(No condensing) | |
| Relative temperature | -25-55℃C | |
| Maximum noise level at full load (at 1m) | ＜40dBA@1M | |
Product parameters:
| Model | AK1500 | |
| Installation method | Tower type UPS | |
| Main topology | L+N+PE | |
| Capacity | 1500VA/900W | |
| Input | ||
| Input voltage | 110/120VAC or 220/230/240VAC | |
| Voltage range | 86-140VAC or 170-285VAC | |
| Input frequency | 50/60Hz | |
| Factor | 0.999 | |
| Output | ||
| Main topology | L+N+PE | |
| Output voltage | 110/120VAC or 220/230/240VAC | |
| Voltage range (battery mode) | ±10% | |
| Frequency synchronous range | 50Hz or 60Hz ± 1HZ | |
| Factor | 0.6 | |
| Transfer time | 6ms | |
| Output waveform | Simulated sine wave | |
| Communication and Management | ||
| Communication interface | RS232/USB/RJ11/RJ45 | |
| Control panel | Multi functional LCD,status and display console | |
|
Standard UPS |
||
|
Standard UPS battery |
Battery type | VRLA |
| Charging current | 1A | |
| Battery voltage | 24V | |
| Battery capacity | 9AH | |
|
Machinedata |
Size (MM) | 365*140*165 |
| Weight (KG) | 12.6KG | |
|
Packing data |
Size (MM) | 450*436*250 |
| Weight (KG) | 25.2KG | |
| UPS Number | 2 | |
|
Environment |
||
| Operating humidity | 20%-95%(No condensing) | |
| Relative temperature | -25-55℃C | |
| Maximum noise level at full load (at 1m) | ＜40dBA@1M | |
Product parameters:
| Model | AK2000 | |
| Installation method | Tower type UPS | |
| Main topology | L+N+PE | |
| Capacity | 2000VA/1200W | |
| Input | ||
| Input voltage | 110/120VAC or 220/230/240VAC | |
| Voltage range | 86-140VAC or 170-285VAC | |
| Input frequency | 50/60Hz | |
| Factor | 0.999 | |
| Output | ||
| Main topology | L+N+PE | |
| Output voltage | 110/120VAC or 220/230/240VAC | |
| Voltage range (battery mode) | ±10% | |
| Frequency synchronous range | 50Hz or 60Hz ± 1HZ | |
| Factor | 0.6 | |
| Transfer time | 6ms | |
| Output waveform | Simulated sine wave | |
| Communication and Management | ||
| Communication interface | RS232/USB/RJ11/RJ45 | |
| Control panel | Multi functional LCD,status and display console | |
|
Standard UPS |
||
|
Standard UPS battery |
Battery type | VRLA |
| Charging current | 1A | |
| Battery voltage | 24V | |
| Battery capacity | 9AH | |
|
Machinedata |
Size (MM) | 365*140*165 |
| Weight (KG) | 17KG | |
|
Packing data |
Size (MM) | 450*436*250 |
| Weight (KG) | 34KG | |
| UPS Number | 2 | |
|
Environment |
||
| Operating humidity | 20%-95%(No condensing) | |
| Relative temperature | -25-55℃C | |
| Maximum noise level at full load (at 1m) | ＜40dBA@1M | |
