Offline UPS Backup Power Supply 500VA–3000VA
500VA–3000VA cost-effective offline UPS with LCD display, ≤6ms transfer time, surge protection and battery backup for PCs, routers, network equipment, home office devices and small electronics.
SHANPU offline UPS is a cost-effective standby backup power supply designed for PCs, routers, network equipment, home office devices and small electronic loads. Available from 500VA to 3000VA, it provides battery backup and surge protection during power outages, voltage fluctuations and unstable grid conditions.
With compact design, LCD display, automatic detection, overload protection, input short-circuit protection and low-noise operation below 40dB, this offline UPS is an ideal entry-level power protection solution for home offices, small businesses, retail terminals and B2B wholesale buyers.
Key Features of SHANPU Offline UPS
• 500VA, 600VA, 1000VA, 2000VA and 3000VA capacity options
• Cost-effective standby UPS for daily backup power protection
• Suitable for PCs, routers, network equipment and office electronics
• LCD display for easy UPS status monitoring
• ≤6 ms transfer time for fast battery backup switching
• Built-in overload protection and input short-circuit protection
• Standard battery and external battery models available
• Low-noise operation below 40dB
• Compact design for home office and small business installation
• Suitable for B2B wholesale, retail terminals, small offices and home backup power use
Offline UPS Technical Specifications
Compare SHANPU MT500, MT600, MT1000, MT2000 and MT3000 offline UPS models by capacity, input voltage, transfer time, battery configuration, external battery support, LCD display, protection functions, size, weight and operating environment.
| Model | MT500 | MT600 | MT1000 | MT2000 | MT3000 | |
| capacity | 500VA/300W | 600VA/360W | 1000VA/600W | 2000VA/1200W | 3000VA/1800W | |
| Input | ||||||
| Input voltage | 1 10/120/200/220/230/240vac | |||||
| Input voltage range | 140-280V | |||||
| Input frequency | 50±HZ | |||||
| output | ||||||
| BattEry voltage | 110/120/200/220/230/240vac | |||||
| output voltage range | ±10% | |||||
| output frequency | 50±HZ | |||||
| Transfer time | ≤ 6 ms | |||||
| Battery | ||||||
|
Standard UPS |
Battery voltage | 12V | 24V | 24V | 24V | |
| Battery model | 12V/7AH | 12V/9AH | 12V/9AH | 12V/9AH | ||
| Battery quantity | 1 | 1 | 2 | 4 | ||
| charging time | -1690% 10 - 16 Hours to 90% full capacity | |||||
| Model | MT500(S) | MT600(S) | MT1000(S) | MT2000(S) | MT3000(S) | |
| External battery Ups | BattEry voltage | 12V | 12V | 24V | 24V | 24V |
| Battery model | External battEry | |||||
| Battery quantity | ||||||
| charging time | Depends on the external battery capacity | |||||
| Display description | ||||||
| Display status | LCD | |||||
| protection function | Automatic detection and discharge protection, input short circuit protection, overload protection | |||||
| Warning sound | ||||||
| Battery mode | 4 beeps every 4 seconds | |||||
| Low battery | Beep every second | |||||
| overload | Beep every second | |||||
| Error | continuous Beep | |||||
| Physical property | ||||||
| stardard Ups |
size (MM) | 320 * 90 * 140 | 365*140*165 | 165*140*165 | 395*145*210 | |
| Weight (KG) | 5.1 | 5.7 | 12.6 | 21 | ||
| External battery Ups |
size (MM) | 320*90*140 | 365*140*165 | 395*145*210 | ||
| weight (KG) | 3.5 | 4.2 | 10.2 | 13.7 | ||
| Usage environment |
||||||
| Humidity |
0-90% 0-40℃ 0-90% Humidity and 0-40°C Temperature |
|||||
| Noise |
<40 dB | |||||
FAQ
1. What is an offline UPS?
An offline UPS, also known as a standby UPS, provides backup battery power when the mains power fails. It is suitable for basic power protection for computers, routers, network equipment and home office electronics.
2. What capacity options are available?
This series includes 500VA, 600VA, 1000VA, 2000VA and 3000VA models, allowing users to select the right UPS according to load size and backup power requirements.
3. What devices can this offline UPS protect?
It can protect PCs, routers, modems, network devices, POS systems, office workstations, small electronic devices and home office equipment.
4. What is the transfer time?
The transfer time is ≤6ms, allowing the UPS to switch quickly to battery power when mains power is interrupted.
5. Does this UPS have an LCD display?
Yes. The UPS is equipped with an LCD display to show operating status and help users monitor the power system more easily.
6. Does it support external batteries?
Yes. Some models are available with external battery support, allowing users to configure backup time according to application needs.
7. Is this UPS suitable for servers?
This offline UPS is suitable for basic backup power needs. For critical servers, data centers or high-availability systems, an online UPS is recommended.
8. What protection functions are included?
The UPS includes automatic detection, discharge protection, input short-circuit protection and overload protection.
9. Is this UPS suitable for wholesale buyers?
Yes. Its compact design, cost-effective pricing and multiple capacity options make it suitable for B2B wholesale, retail channels and small office power protection projects.
10. What information should I provide for a quotation?
Please provide the required capacity, quantity, input/output voltage, plug or socket type, battery backup time requirement, destination country and application scenario.
